Fully Automatic Vision Measuring System

Execute programmable software to achieve integrated and precise batch measurements; equipped with SPC statistical capabilities to enhance product analysis; features automatic focusing and recognition, significantly improving inspection efficiency.

Optical	Manual、Semi-automatic、 Fully automatic、2D、2.5D
magnification	Optical magnification: 0.7-4.5times Image magnification: 30-225 0.5μm times

Key attributes

Type	Testing Machine
Power	/
Voltage	220V Electrical Equipment
Accuracy Class	High Accuracy
Accuracy	/
Place of Origin	Jiangsu, China
Customized Support	OEM, ODM
Protection Class	/
Brand Name	QianTong
Application	Laboratory Testing
Warranty	1 Year
Travel (mm)	400 × 300 × 200
Overall Dimensions (mm)	725 × 877 × 1180
Table Size (mm)	560 × 460
Weight (kg)	350
Measurement Accuracy (μm)	XY (2.5 + L / 200) μm, Z-axis: 0.005 μm
Grating Scale Resolution	0.5 μm
Guide Rail / Camera	Japan THK / US TEO Color Industrial HD CCD
Magnification	Optical: 0.7–4.5×, Image: 30–225×
Power Source	220V, 50Hz
