QE-UH100 Portable UCI Hardness Tester
The QE-UH100 is a professional portable hardness tester using the Ultrasonic Contact Impedance method. Its compact probe provides fast, minimally destructive measurements on thin components, localized areas, finished surfaces, weld zones, and geometries that are difficult to test with conventional bench-mounted equipment.
Key Product Information
| Test method | Ultrasonic Contact Impedance |
| Standard test force | HV5, 50 N / 5 kgf |
| Displayed hardness ranges | 20–70 HRC, 8–650 HB, 8–1500 HV |
| Measurement time | Approximately 2 seconds |
| Reading average | Selectable from 1–99 measurements |
| Internal memory | Up to 12,400 readings |
| Data output | USB connection |
| Power source | Rechargeable lithium-ion battery |
| Display unit weight | Approximately 0.3 kg |
| Warranty | 12 months |
Standards supported: ASTM A1038, DIN 50159, ASTM E140 and ISO 18265.
Canadian Support
Technical assistance with equipment selection
Warranty Included
Manufacturer warranties on all equipment
Installation & Training
On-site or installation and hands-on training
Technical Specifications
| Model | QE-UH100 |
| Measurement principle | Ultrasonic Contact Impedance |
| Standard probe | A probe, HV5 |
| Standard probe test force | 50 N / 5 kgf |
| Hardness scales displayed | HRC, HB and HV |
| Rockwell C range | 20–70 HRC |
| Brinell range | 8–650 HB |
| Vickers range | 8–1500 HV |
| Typical relative average error | Approximately 3–5% with proper calibration and test conditions |
| Measurement time | Approximately 2 seconds |
| Reading averaging | 1–99 readings |
| Measurement memory | Up to 12,400 readings |
| Named measurement groups | Up to 100 |
| Additional calibrations | Up to 5 per scale |
| User-defined scales | Up to 3 |
| Limit indication | Upper and lower threshold indication |
| Minimum flat positioning area | From approximately 1 mm |
| Minimum positioning area inside a slot | From approximately 5 mm |
| Communication | USB |
| Battery | Rechargeable lithium-ion |
| Display unit dimensions | 121 × 69 × 41 mm |
| Display unit weight | Approximately 0.3 kg |
| Standard A-probe weight | Approximately 0.3 kg |
| Operating temperature | −15°C to +35°C |
| Warranty | 12 months |
Actual performance depends on the material, surface preparation, component thickness, probe position and calibration used.
Available UCI Probes
| Probe | Test Force | Recommended Application |
|---|---|---|
| A probe | 50 N / 5 kgf | General-purpose hardness testing |
| H probe | 10 N / 1 kgf | Thin, polished or coated components |
| C probe | 100 N / 10 kgf | Heavy components and less-prepared surfaces |
| K probe | 50 N / 5 kgf | Tubes, tanks and curved surfaces |
| AL probe | 50 N / 5 kgf | Grooves, pinholes, gear teeth and restricted areas |
Applicable Standards
- ASTM A1038 — Portable hardness testing using the UCI method
- DIN 50159 — Hardness testing using the UCI method
- ASTM E140 — Hardness conversion relationships
- ISO 18265 — Conversion of hardness values for metallic materials
Applications
- Incoming material inspection
- Weld and heat-affected-zone testing
- Gear teeth and machined components
- Thin and lightweight metallic parts
- Shafts, tubes, tanks and pressure vessels
- Finished and polished surfaces
- Heat-treatment verification
- Maintenance and field inspection
- Aerospace and automotive components
- Production quality control
What's Included
✓ QE-UH100 electronic display unit
✓ Rechargeable lithium-ion battery
✓ UCI A probe — HV5, 50 N / 5 kgf
✓ Probe connection cable
✓ Battery charger
✓ USB computer connection cable
✓ Protective soft case
✓ Arm-mounting cuff
✓ Carrying and storage bag
✓ Operating manual
Downloads
Brochure
QE-UH100 Portable UCI Hardness Tester
Why Choose This Model?
Fast UCI Measurement
Produces a hardness result in approximately two seconds, supporting efficient inspection of multiple components and test locations.
Access to Difficult Areas
The compact probe can measure grooves, weld zones, gear teeth, narrow openings, tubes and localized surfaces that may be inaccessible to conventional hardness testers.
Flexible Probe Selection
Optional probes with different test forces and geometries allow the instrument to be configured for thin parts, polished surfaces, heavy components and complex shapes.
Professional Data Management
Stores thousands of readings, supports named measurement groups and transfers inspection data to a computer through USB.
Need help selecting the right configuration?
Our application specialists are here to help you choosing the best solution for your materials and workflow.
Talk to an expert
Get expert advice on models, accessories and standards.
- 647-948-7714
- info@qmnequipment.com
- Mon-Friday: 9:00am to 6:00pm ET
Frequently Asked Questions
What materials can the QE-UH100 test?
It is primarily designed for metals, including steel, stainless steel, cast materials and non-ferrous alloys when an appropriate calibration is available.
Does the tester damage the test surface?
UCI testing produces a very small indentation and is generally considered minimally destructive.
Can it test thin components?
Yes. The optional low-force H probe is recommended for thin, polished or coated components. Suitability depends on material thickness and support conditions.
Does it require surface preparation?
The measurement area should be clean, stable and sufficiently smooth. Coarse or oxidized surfaces may require grinding or polishing.
Can test results be transferred to a computer?
Yes. Stored measurements can be transferred using the supplied USB connection.
