QE-CH200 Portable Combined UCI and Leeb Hardness Tester
A professional dual-method portable hardness tester combining Ultrasonic Contact Impedance (UCI) and Leeb rebound measurement in one instrument. The QE-CH200 is designed for field and production testing of thin, small, polished, surface-hardened and complex components, as well as large castings, forgings, pipelines and installed machinery.
Key Product Information
| Test methods | UCI and Leeb rebound |
| Displayed hardness ranges | 20–70 HRC, 8–650 HB, 8–1500 HV |
| Standard UCI probe | Type A, HV5, 50 N/5 kgf |
| Standard Leeb device | Type D |
| Typical measurement time | Approximately 2 seconds |
| Reading average | Selectable from 1–99 measurements |
| Internal memory | 12,400 readings |
| Named data blocks | Up to 100 |
| Data output | USB connection to PC |
| Power | Rechargeable Li-ion battery |
Canadian Support
Technical assistance with equipment selection
Warranty Included
Manufacturer warranties on all equipment
Installation & Training
On-site or installation and hands-on training
Technical Specifications
| Measurement methods | UCI and Leeb rebound |
| Rockwell C range | 20–70 HRC |
| Brinell display/conversion range | 8–650 HB |
| Vickers display/conversion range | 8–1500 HV |
| Typical relative average error | 3–5% with regular calibration |
| Measurement duration | Approximately 2 seconds |
| Measurement area | From 1 mm on a flat surface; from 5 mm inside a slot |
| Measurements used for averaging | 1–99 |
| Internal memory | 12,400 readings |
| Named measurement blocks | Up to 100 |
| User calibrations | Five for each hardness scale |
| Additional user-defined scales | Three |
| Data connection | USB to PC |
| Power supply | Rechargeable Li-ion battery |
| Electronic unit dimensions | 121 × 69 × 41 mm |
| Electronic unit weight | Approximately 0.3 kg |
| Standard UCI probe weight | Approximately 0.3 kg |
| Standard Leeb D device weight | Approximately 0.15 kg |
| Operating temperature | −15 to +35 °C |
| Warranty | 12 months |
Measurement results outside verified reference ranges may involve conversion or extrapolation. Confirm their acceptability under the applicable inspection procedure.
Probe Selection
| Probe | Method and Load | Typical Minimum Condition | Recommended Application |
|---|---|---|---|
| UCI A | HV5, 50 N/5 kgf | 1 kg; 3 mm; Ra 1.6 | General UCI hardness testing |
| UCI H | HV1, 10 N/1 kgf | 1 kg; 2 mm; Ra 0.8 | Thin components, coatings and hardened layers |
| UCI C | HV10, 100 N/10 kgf | 1 kg; 4 mm; Ra 3.2 | Less-prepared surfaces and heavy parts |
| UCI K | HV5, 50 N/5 kgf | 1 kg; 3 mm; Ra 1.6 | Internal surfaces of tubes and tanks |
| UCI AL | HV5, 50 N/5 kgf | 1 kg; 3 mm; Ra 1.6 | Grooves, pinholes and between gear teeth |
| Leeb D | Standard impact device | 3 kg; 6 mm; Ra 3.2 | General rebound hardness testing |
| Leeb E | High-hardness impact device | 3 kg; 6 mm; Ra 3.2 | High-hardness materials |
| Leeb G | Higher-impact device | 8 kg; 55 mm; Ra 7.6 | Large, rough or inhomogeneous components |
Minimum conditions are application guidance. Component support, coupling, curvature and material properties can affect suitability.
Applicable Standards
| ASTM A1038 | Portable hardness testing using the UCI method |
| DIN 50159 | UCI hardness testing of metallic materials |
| ASTM A956 | Leeb rebound hardness testing of steel products |
| ISO 16859 | Leeb hardness testing of metallic materials |
| ASTM E140 | Hardness conversion tables for metals |
| ISO 18265 | Conversion of hardness values for metallic materials |
Compliance requires the appropriate probe, surface condition, calibration, reference blocks and inspection procedure.
UCI or Leeb: Which Method Should Be Used?
| Workpiece or Condition | Recommended Method | Reason |
|---|---|---|
| Thin, small or lightweight component | UCI | Lower thickness and mass requirements |
| Surface-hardened layer or electroplated surface | UCI | Small indentation and controlled test load |
| Gear tooth, groove, bore or restricted location | UCI with specialized probe | Better access to localized test areas |
| Large casting, forging or shaft | Leeb | Rapid rebound testing on heavy components |
| Pipeline, rail or installed machinery | Leeb | Suitable for large components that cannot be moved |
| Rough or structurally inhomogeneous component | Leeb G option | Higher-impact device for heavy, rough sections |
Applications
- Heat-treated and surface-hardened components
- Thin-walled and lightweight metal parts
- Gear teeth, shafts, grooves and blind holes
- Electroplated and coated metallic surfaces
- Castings, forgings and welded structures
- Stainless steel and corrosion-resistant alloys
- Cast iron, aluminum, bronze, brass and copper alloys
- Pipelines, rails and construction components
- Production quality control
- Incoming material inspection
- Maintenance and field inspection
- Aerospace, shipbuilding, power generation and oil and gas
What's Included
✓ QE-CH200 electronic display unit
✓ UCI A probe — HV5, 50 N/5 kgf
✓ Type D Leeb impact device
✓ Probe connection cables
✓ Rechargeable Li-ion battery
✓ Battery charger
✓ USB PC connection cable
✓ Data-management software
✓ Protective carrying and storage case
✓ Operating manual
✓ Factory test certificate
Downloads
Brochure
QE-CH200 Portable Combined UCI and Leeb Hardness Tester
Why Choose This Model?
Two Testing Methods
Switch between UCI and Leeb testing using one electronic display unit, reducing the need to purchase and carry two separate instruments.
Thin to Heavy Components
Use UCI for thin, lightweight, polished and surface-hardened components. Use Leeb for large, heavy and rough industrial parts.
Fast and Efficient
Obtain readings in approximately two seconds, calculate averages and organize up to 12,400 stored measurements.
Built for Field Inspection
Compact battery-powered construction, physical operating buttons, a bright colour display and USB data transfer support production and on-site inspection.
Need help selecting the right configuration?
Our application specialists are here to help you choosing the best solution for your materials and workflow.
Talk to an expert
Get expert advice on models, accessories and standards.
- 647-948-7714
- info@qmnequipment.com
- Mon-Friday: 9:00am to 6:00pm ET
Frequently Asked Questions
What is the difference between UCI and Leeb hardness testing?
UCI uses a controlled-load diamond indenter and is better suited to thin, small, polished, surface-hardened or complex components. Leeb measures the rebound of an impact body and is generally better suited to large and heavy components.
Which probes are supplied as standard?
The standard configuration includes an HV5, 50 N UCI A probe and a Type D Leeb impact device.
Can the tester measure thin components?
Yes. The UCI method is intended for thinner and smaller components. The exact minimum thickness depends on the selected probe, material, surface condition and how the component is supported.
Can it test castings and forgings?
Yes. The Type D Leeb device is suitable for many large castings and forgings. A Type G device may be recommended for particularly large, rough or structurally inhomogeneous components.
Does the tester store inspection results?
Yes. The instrument stores up to 12,400 readings in as many as 100 named data blocks.
